PRECISION INVENTORY

Operating Wavelength

1310±25 nm

Insertion Loss

≤3.0 dB

Maximum Optical Input Power

200 mW

Split Ratio

48/52~52/48

Operating Wavelength

830±20 nm

Insertion Loss

≤3.5 dB

Maximum Optical Input Power

10 mW

Split Ratio

48/52~52/48

Measurement Range

g ±20

Bandwidth

Hz 100

Zero Bias Stability

mg ≤0.05

Zero Bias Repeatability

mg ≤0.3

Measurement Range

°/s ±500

Bandwidth

Hz 95

Scale Factor Nonlinearity

ppm ≤500

Scale Factor Repeatability

ppm ≤800

Gyroscope Bias Stability (1σ)

0.05 °/hr

Angular Random Walk

0.02 °/√hr

Gyroscope Dynamic Range

±400 °/s

Accelerometer Bias Stability (1σ)

0.01 mg

Input Range

±60 g

Bias

<4 mg

One-year Composite Repeatability

<160 µg

Temperature Sensitivity

<30 µg/°C

Power Supply Voltage

V 5 ± 0.2

Operating Current

mA ≤10

Weight

g ≤1.5

Outline Dimensions

mm 10 × 10 × 3

Power Supply Voltage

V 5 ± 0.2

Operating Current

mA ≤10

Weight

g ≤1.5

Outline Dimensions

mm 13.6 × 8 × 2.8

Power Supply Voltage

5 ± 0.2 V

Operating Current

120 ± 5 mA

Weight

78 ± 5 g

Startup Time

≤2 s

Power Supply Voltage

5 ± 0.2 V

Operating Current

40 ± 10 mA

Weight

≤50 g

Initialization Time

≤1 s

Measurement Range

±30 ±10

Bandwidth

200 200

Zero Bias Stability

≤0.3 ≤0.3

Zero Bias Repeatability

≤0.5 ≤0.5

Measurement Range

°/s ±100

Bandwidth

Hz 12.5

Scale Factor Nonlinearity

ppm ≤200

Scale Factor Repeatability

ppm ≤50

Measurement Range

±450 °/s

In-Run Bias Stability

≤1.0 °/h

Angular Random Walk

≤0.12 °/√h

Scale Factor Error

≤0.05 %

Input Range

±60 g

Bias Error

≤ 4 mg

Bias Long-Term Repeatability (1 Year, over temperature)

≤ 160 (3σ) µg

Bias Temperature Sensitivity

≤ 30 µg/°C

Power Supply Voltage

V 5 ± 0.2

Operating Current

mA ≤10

Weight

g ≤1.5

Outline Dimensions

mm 10 × 10 × 2.95

Power Supply Voltage

5 ± 0.2 V

Operating Current

170 ± 5 mA

Weight

67 ± 5 g

Startup Time

≤2 s

Power Supply Voltage

5 ± 0.2 V

Operating Current

≤150 mA

Weight

90 ± 5 g

Startup Time

≤2 s

Operating Wavelength

1550±25 nm

Insertion Loss

≤4.0 dB

Maximum Optical Input Power

200 mW

Split Ratio

48/52~52/48

Measurement Range

±20 ±10

Bandwidth

200 200

Zero Bias Stability (1σ)

≤1 ≤0.5

Zero Bias Repeatability (1σ)

≤2 ≤0.5

Measurement Range

±450 °/s

In-Run Bias Stability

≤1.5 °/h

Angular Random Walk

≤0.15 °/√h

Scale Factor Error

≤0.1 %

Input Range

±60 g

Bias Error

≤4 mg

Bias Long-Term Repeatability (1 year)

≤1 (3σ) mg

Bias Temperature Sensitivity

≤50 µg/°C

Power Supply Voltage

V 5 ± 0.2

Operating Current

mA ≤25

Weight (excluding leads)

g ≤25

Startup Time

s ≤2

Power Supply Voltage

5 ± 0.2 V

Operating Current

19 ± 5 mA

Weight

15 ± 5 g

Startup Time

≤2 s

Power Supply Voltage

5 ± 0.2 V

Operating Current

40 mA

Weight

20 ± 5 g

Operating Wavelength

1550±25 nm

Insertion Loss

≤3.0 dB

Maximum Optical Input Power

200 mW

Split Ratio

48/52~52/48

Measurement Range

±20 ±10

Bandwidth

200 200

Zero Bias Stability (1σ)

≤0.5 ≤0.3

Zero Bias Repeatability (1σ)

≤1 ≤0.5

Measuring Range

— °/s

Bias Instability (Allan Variance)

Allan Variance °/h

Bias Stability (RMS, 10s)

Room temperature °/h

Bias Drift (Full Temp, RMS)

ΔT = 1°C/min °/h

Measurement Range

°/s ±300

Zero Bias

°/s ±0.05

Zero Bias Stability (10s)

°/h ≤1

Zero Bias Repeatability

°/h ≤5

Measurement Range

— °/s

Bias Instability

Allan Variance °/h

Bias Stability

1s smoothing, RMS, room temperature °/h

Full Temp Bias Variation

10s smoothing, RMS, temp rate 1°C/min °/h

Range

±60g ±60g

Threshold

5 µg 5 µg

Bias K₀/K₁

≤±7 mg ≤±5 mg

Scale Factor K₁

1.0 ± 0.2 mA/g 1.0 ± 0.2 mA/g

Power Supply Voltage

V 5 ± 0.2

Operating Current

mA 51 ± 5

Weight (excluding leads)

g 8 ± 2

Startup Time

s ≤2

Power Supply Voltage

V 5 ± 0.2

Operating Current

mA 19 ± 5

Weight

g 12 ± 5

Startup Time

s ≤2

Power Supply Voltage

5 ± 0.2 V

Operating Current @12V

135 ± 10 mA

Weight

75 ± 5 g

Measurement Range

°/s ±400

Zero Bias Stability¹

°/h ≤5

Zero Bias Temperature Drift²

°/h(1σ) ≤15

Zero Bias g Sensitivity

°/h/g ≤1

Measurement Range

°/s ±400

Zero Bias Stability¹

°/h ≤1

Zero Bias Temperature Drift²

°/h(1σ) ≤5

Zero Bias g Sensitivity

°/h/g ≤1

Range

±50g, ±60g, ±70g ±50g, ±60g, ±70g

Threshold

5 µg 5 µg

Bias K₀/K₁

≤±3 mg ≤±3 mg

Scale Factor K₁

1.05–1.30 mA/g 1.05–1.30 mA/g

Power Supply Voltage

V 5 ± 0.2

Operating Current

mA 30 ± 5

Weight (excluding leads)

g 12 ± 2

Startup Time

s ≤2

Power Supply Voltage

5 ± 0.2 V

Operating Current @12V

<300 mA

Weight (Excl. cables)

151 ± 10 g

Board Configuration

Internal –

Measurement Range

±4000 ±4000

Zero Bias Stability

≤30 ≤50

Full Temperature¹ Zero Bias Stability

≤100

Zero Bias Repeatability

≤30 ≤50

Range

±70g, ±100g ±70g, ±100g

Threshold

5 µg 5 µg

Bias K₀/K₁

≤±3 mg ≤±3 mg

Scale Factor K₁

0.8–1.2 mA/g 0.8–1.2 mA/g

Power Supply Voltage

V 5 ± 0.2

Operating Current

mA 60 ± 5

Weight (excluding leads)

g 38 ± 5

Startup Time

s ≤3

Measurement Range

+3600 -3600

Scale Factor

2010 1990

Scale Factor Nonlinearity

150

Zero Bias¹

0.05 -0.05

External Diameter

22.2 mm

Pendulum Thickness

2.25 mm

Pendulum Gap

2.5 mm

Base Thickness

0.78 mm

Power Supply Voltage

V 5 ± 0.2

Operating Current

mA 75 ± 5

Weight (excluding leads)

g 21 ± 2

Startup Time

s ≤1

Measurement Range

°/s ±100

Zero Bias Stability¹

°/h ≤0.1

Zero Bias Temperature Drift²

°/h(1σ) ≤5

Zero Bias g Sensitivity

°/h/g ≤0.5

Power Supply Voltage

V 5 ± 0.2

Operating Current

mA 80 ± 5

Weight (excluding leads)

g 30 ± 5

Startup Time

s ≤3

Power Supply Voltage

V 5 ± 0.2

Operating Current

mA 106 ± 5

Weight

g 75 ± 5

Startup Time

s ≤2

Inner Diameter

21.0±0.1 mm

Outer Diameter

≤33.0 mm

Mean Diameter

28.0±0.5 mm

Height

15.0±0.1 mm

Inner Diameter

130.0±0.5 mm

Outer Diameter

≤150.0 mm

Mean Diameter

140.0±0.5 mm

Height

15.0±0.1 mm

Inner Diameter

80.0±0.1 mm

Outer Diameter

≤100.0 mm

Mean Diameter

90.0±0.5 mm

Height

25.0±0.1 mm

Inner Diameter

15~250 mm

Layer Count

10~120 /

Fiber Length

20~20000 m

Center Wavelength

980 ± 3 nm

Output Power

110 mW

Spectral Width (FWHM)

≤ 1 nm

Power Stability (8hrs)

≤ ±1 %

Center Wavelength

1530 nm

Output Power

≤50 mW

Spectral Width

7 nm

Power Stability @25°C

1 %

Operating Voltage

±5 ± 0.3 V

Noise Voltage

0.4 mV

Voltage Response

0.9* (Selectable 20kΩ ∼ 1200kΩ) V/W

Dark Output Voltage

-1.2 ∼ -0.6 or -2.0 ∼ -1.4 V

Operating Voltage

±5 ± 0.3 V

Noise Voltage

0.4 mV

Voltage Response

0.9* (Selectable 20kΩ ∼ 1200kΩ) V/W

Dark Output Voltage

-1.2 ∼ -0.6 or -2.0 ∼ -1.4 V

Pass Wavelength

1528 ~ 1568 nm

Reflect Wavelength

980 ± 10 nm

Signal Insertion Loss (Signal to Com)

≤ 1.0 dB

Pump Insertion Loss (Pump to Com)

≤ 0.5 dB

Azimuth Accuracy

≤3.5 arcsec

Measurement Time

≤13 min

Main Unit Weight

≤13.5 kg

Data Storage

100 groups

Azimuth Accuracy

≤2.5 arcsec

Measurement Time

≤14 min

Main Unit Weight

≤14 kg

Data Storage

100 groups
