Quartz Flexure Accelerometer (±50–±70 g)

Quartz Flexure Accelerometer · JDSJ25TK01

Inertial navigation-grade quartz flexure accelerometer with ±50 g, ±60 g, or ±70 g range options, 5 µg threshold, and bias repeatability down to ≤10 µg (1σ, 1 month) on the enhanced tier. Ø25.4 × 30 mm and ≤80 g, 800–2500 Hz bandwidth, 100 g shock resistance, −55 °C to +85 °C operation.

General SpecificationsRange: ±50g, ±60g, ±70g
Physical and Environmental SpecificationsBandwidth: 800–2500 Hz
General SpecificationsThreshold: 5 µg

Read full specifications and measurement conditions ↓

Request a quote View specifications

Quartz Flexure Accelerometer (±50–±70 g) — JDSJ25TK01Product reference

Confirm configuration, interfaces and documentation with your inquiry.

The JDSJ25TK01 series quartz flexure accelerometer is a high-precision inertial navigation-grade sensor renowned for its exceptional long-term stability, repeatability, startup performance, environmental adaptability, and high reliability. It is suitable for both static and dynamic testing and also functions effectively as a standard vibration and tilt sensor. The accelerometer’s output current maintains a linear relationship with the applied force or acceleration, allowing users to select appropriate sampling resistors to achieve high-precision outputs. Additionally, an internal temperature sensor can be integrated upon request to compensate for bias and scale factor variations, thereby minimizing environmental temperature influences.

Key Features

Exceptional long-term stability
Superior repeatability performance
Excellent startup characteristics
High environmental adaptability
Enhanced reliability design
Linear output current to acceleration relationship
Customizable sampling resistors
Optional integrated temperature sensor
Low bias temperature coefficient
High shock resistance (100g)
Wide operating temperature range (-55°C to +85°C)

Applications

High-precision inertial navigation systemsAerospace applicationsAviation systemsMaritime navigationVibration isolation testingPrecision instruments and equipmentStandard vibration measurementTilt sensing applications

Technical Specifications

General Specifications

Range: ±50g, ±60g, ±70g
Threshold: 5 µg
Bias K₀/K₁: ≤±3 mg
Scale Factor K₁: 1.05–1.30 mA/g
Second-Order Nonlinearity Coefficient K₂: ≤±15 µg/g²≤±10 µg/g²
0g 4-Hour Short-Term Stability: ≤10 µg
1g 4-Hour Short-Term Stability: ≤10 ppm

Performance Specifications

Bias Comprehensive Repeatability σK₀ (1σ, 1 month): ≤15 µg≤10 µg
Scale Factor Comprehensive Repeatability σK₁/K₁ (1σ, 1 month): ≤20 ppm≤10 ppm
Nonlinearity Coefficient Comprehensive Repeatability K₂/K₁ (1σ, 1 month): ≤±15 µg/g²≤±10 µg/g²
Bias Temperature Coefficient (Average over Full Temperature Range): ≤±20 µg/°C≤±10 µg/°C
Scale Factor Temperature Coefficient (Average over Full Temperature Range): ≤±30 ppm/°C≤±10 ppm/°C
Noise (Sampling Resistor at 840 Ω): ≤8.4 mV≤5 mV

Physical and Environmental Specifications

Natural Frequency: 400–800 Hz
Bandwidth: 800–2500 Hz
Random Vibration: 6g (20–2000 Hz)
Shock: 100g, 8 ms, 1/2 sin
Operating Temperature Range: -55°C to +85°C
Storage Temperature Range: -60°C to +120°C
Dimensions: Ø25.4 × 30 mm
Weight: ≤80 g

Electrical Specifications (Common to All Models)

Power Supply: ±12 to ±15 V
Power Consumption: ≤±20 mA
Temperature Sensor: Customizable (AD590, PT1000, 18B20)
Pin Configuration: 10-pin standard (customizable)

[1]Two performance tiers are offered; where two figures are shown for one parameter they correspond to the standard and enhanced tiers — confirm tier at inquiry.
[2]Repeatability figures are 1σ values over a 1-month composite test; test intervals can be customized (1, 3, 6, or 12 months).

Package Information

Technical Drawings

General Accelerometer Outline Drawing — Dimensions Drawingdimensions

Accelerometer with U-Shaped Mounting Hole — Dimensions Drawingdimensions

Accelerometer with U-Shaped Mounting Hole and 8 Pins — Dimensions Drawingdimensions

Accelerometer with Square Outline Dimensions — Dimensions Drawingdimensions

Technical Notes

Testing intervals can be customized based on user needs, such as 1 month, 3 months, 6 months, or 12 months
Outline dimensions can be slightly adjusted according to user installation requirements
