High-Range Quartz Flexure Accelerometer (±70–±100 g)

Quartz Flexure Accelerometer · JDSJ25TK02

High-range quartz flexure accelerometer with ±70 g or ±100 g options, 5 µg threshold, and bias repeatability down to ≤10 µg (1σ, 1 month) on the enhanced tier. Ø25.4 × 30 mm and ≤80 g, 800–2500 Hz bandwidth, −55 °C to +85 °C operation, suited to high-g environments.

General SpecificationsRange
±70g, ±100g
Physical and Environmental SpecificationsBandwidth
800–2500 Hz
General SpecificationsThreshold
5 µg
Read full specifications and measurement conditions ↓
Request a quote View specifications
High-Range Quartz Flexure Accelerometer (±70–±100 g)
JDSJ25TK02Product reference

Confirm configuration, interfaces and documentation with your inquiry.

The JDSJ25TK02 series quartz flexure accelerometer is a high-precision, high-range inertial navigation-grade accelerometer (up to 100g). It boasts excellent long-term stability, repeatability, startup performance, environmental adaptability, and high reliability. Suitable for both static and dynamic testing, it also functions as a standard vibration and tilt sensor. The accelerometer’s output current maintains a linear relationship with the applied force or acceleration, allowing users to select appropriate sampling resistors to achieve high-precision outputs. Additionally, an internal temperature sensor can be integrated upon request to compensate for bias and scale factor variations, thereby minimizing environmental temperature influences.

Key Features

  • High measurement range (up to 100g)
  • Exceptional long-term stability
  • Superior repeatability performance
  • Excellent startup characteristics
  • High environmental adaptability
  • Enhanced reliability design
  • Linear output current to acceleration relationship
  • Customizable sampling resistors
  • Optional integrated temperature sensor
  • Low bias temperature coefficient
  • High shock resistance
  • Wide operating temperature range (-55°C to +85°C)

Applications

High-precision inertial navigation systemsAerospace applicationsAviation systemsMaritime navigationVibration isolation testingTilt testing applicationsPrecision instruments and equipmentHigh-g environments

Technical Specifications

General Specifications

Range
±70g, ±100g
Threshold
5 µg
Bias K₀/K₁
≤±3 mg
Scale Factor K₁
0.8–1.2 mA/g
Second-Order Nonlinearity Coefficient K₂
≤±15 µg/g²≤±10 µg/g²
0g 4-Hour Short-Term Stability
≤10 µg
1g 4-Hour Short-Term Stability
≤10 ppm

Performance Specifications

Bias Comprehensive Repeatability σK₀ (1σ, 1 month)
≤15 µg≤10 µg
Scale Factor Comprehensive Repeatability σK₁/K₁ (1σ, 1 month)
≤20 ppm≤15 ppm
Nonlinearity Coefficient Comprehensive Repeatability K₂/K₁ (1σ, 1 month)
≤±10 µg/g²
Bias Temperature Coefficient (Average over Full Temperature Range)
≤±20 µg/°C≤±10 µg/°C
Scale Factor Temperature Coefficient (Average over Full Temperature Range)
≤±30 ppm/°C≤±20 ppm/°C
Noise (Sampling Resistor at 840 Ω)
≤5 mV

Physical and Environmental Specifications

Natural Frequency
400–800 Hz
Bandwidth
800–2500 Hz
Random Vibration
6g (20–2000 Hz)
Shock
100g, 8 ms, 1/2 sin
Operating Temperature Range
-55°C to +85°C
Storage Temperature Range
-60°C to +120°C
Dimensions
Ø25.4 × 30 mm
Weight
≤80 g

Electrical Specifications (Common to All Models)

Power Supply
±12 to ±15 V
Power Consumption
≤±20 mA
Temperature Sensor
Customizable (AD590, PT1000, 18B20)
Pin Configuration
10-pin standard (customizable)
  1. [1]Two performance tiers are offered; where two figures are shown for one parameter they correspond to the standard and enhanced tiers — confirm tier at inquiry.
  2. [2]Repeatability figures are 1σ values over a 1-month composite test; test intervals can be customized (1, 3, 6, or 12 months).

Package Information

Technical Drawings

General Accelerometer Outline Drawing
Dimensions Drawingdimensions

Technical Notes

  1. Testing intervals can be customized based on user needs, such as 1 month, 3 months, 6 months, or 12 months
  2. Outline dimensions can be slightly adjusted according to user installation requirements

Frequently Asked Questions

What is JDSJ25TK02?+

High-range quartz flexure accelerometer with ±70 g or ±100 g options, 5 µg threshold, and bias repeatability down to ≤10 µg (1σ, 1 month) on the enhanced tier. Ø25.4 × 30 mm and ≤80 g, 800–2500 Hz bandwidth, −55 °C to +85 °C operation, suited to high-g environments.

Which specifications are published for JDSJ25TK02?+

General Specifications — Range: ±70g, ±100g; General Specifications — Threshold: 5 µg; General Specifications — Bias K₀/K₁: ≤±3 mg. Measurement conditions: Two performance tiers are offered; where two figures are shown for one parameter they correspond to the standard and enhanced tiers — confirm tier at inquiry. Repeatability figures are 1σ values over a 1-month composite test; test intervals can be customized (1, 3, 6, or 12 months). See the technical specifications for the complete parameter list.
