Three-Axis MEMS Gyroscope Module (±400 °/s)
Three-Axis MEMS Gyroscope Module · JDWZZ3416B
Three-axis MEMS gyroscope module with a ±400 °/s measurement range, 24-bit resolution, and a 1000 Hz sampling rate over a serial interface. Two performance tiers offer zero bias stability of ≤5 °/h or ≤1 °/h; bandwidth and sampling rate are customizable, and single- or dual-axis configurations are available on request.
Measurement Range
±400 °/s
Zero Bias Stability¹
≤5 °/h
Zero Bias Temperature Drift²
≤15 °/h
Product Gallery
The JDWZZ3416A is a high-precision three-axis MEMS gyroscope module designed for real-time angular rate measurement. Featuring a measurement range of ±400°/s with superior zero bias stability (≤5°/h) and excellent g-sensitivity performance (≤1°/h/g), it integrates three precision single-axis MEMS gyroscopes with comprehensive signal processing capabilities. The module offers high-resolution 24-bit output at 1000Hz sampling rate, supported by advanced control circuits and serial communication interface, making it ideal for precise motion sensing applications.
Key Features
- High-performance three-axis measurement:
- Measurement range: ±400°/s
- Superior zero bias stability (≤5°/h)
- Excellent g-sensitivity (≤1°/h/g)
- Low scale factor nonlinearity (≤150ppm)
- Precise orthogonality (6°)
- Advanced data processing:
- 24-bit resolution
- High sampling rate (1000Hz)
- Configurable bandwidth (up to 200Hz)
- Comprehensive signal processing
- Serial port communication interface
- Robust performance characteristics:
- Fast activation time (≤1s)
- Wide operating temperature range (-40°C to +85°C)
- High overload resistance (1500g)
- Low power consumption (≤200mA)
- Flexible power supply (5-8V)
Applications
Technical Specifications
Performance Specifications
- Measurement Range
- ±400 °/s
- Zero Bias Stability¹
- ≤5 °/h
- Zero Bias Temperature Drift²
- ≤15 °/h
- Zero Bias g Sensitivity
- ≤1 °/h/g
- Scale Factor Nonlinearity
- ≤150 ppm
- Orthogonality
- 6 °
- Activation Time
- ≤1 s
- Bandwidth³
- 200 Hz
- Resolution
- 24 bit
- Sampling Rate⁴
- 1000 Hz
- Power Supply Voltage
- 5~8 V
- Current
- ≤200 mA
- Operating Temperature
- -40~+85 °C
- Resistant To Overload
- 1500 g
Performance Specifications
- Measurement Range
- ±400 °/s
- Zero Bias Stability¹
- ≤1 °/h
- Zero Bias Temperature Drift²
- ≤5 °/h
- Zero Bias g Sensitivity
- ≤1 °/h/g
- Scale Factor Nonlinearity
- ≤150 ppm
- Orthogonality
- 6 °
- Activation Time
- ≤1 s
- Bandwidth³
- 200 Hz
- Resolution
- 24 bit
- Sampling Rate⁴
- 1000 Hz
- Power Supply Voltage
- 5~8 V
- Current
- ≤200 mA
- Operating Temperature
- -40~+85 °C
- Resistant To Overload
- 1500 g
- [1]Zero bias stability is specified with 10 s smoothing; two performance tiers are offered (≤5 °/h and ≤1 °/h) — confirm tier at inquiry.
- [2]Bandwidth and sampling rate can be customized per the product notes.
Technical Notes
- 10s smoothing
- Full temperature
- Bandwidth can be customized
- Sampling rate can be customized
