9-DoF MEMS IMU with Magnetic Sensor (≤0.1 °/h Gyro Stability)

MEMS Inertial Measurement Unit (IMU) · JDWZZ3430

Nine-degree-of-freedom MEMS IMU integrating three-axis gyroscope, accelerometer, and magnetic sensor. Gyroscope zero bias stability down to ≤0.1 °/h, accelerometer ≤50 µg, 24-bit gyro resolution with 1000 Hz sampling; multiple range variants (±100 to ±500 °/s) cover stabilization through high-dynamic navigation.

Gyroscope SpecificationsMeasurement Range
±100 °/s
Magnetic Sensor SpecificationsMeasurement Range
±8 G
Gyroscope SpecificationsMeasurement Range
±400 °/s
Read full specifications and measurement conditions ↓
Request a quote View specifications
9-DoF MEMS IMU with Magnetic Sensor (≤0.1 °/h Gyro Stability)
JDWZZ3430Product reference

Confirm configuration, interfaces and documentation with your inquiry.

The JDWZZ3430B is a high-precision 9-DOF MEMS inertial measurement unit integrating three complementary sensor systems. The gyroscope provides ±100°/s measurement range with exceptional zero bias stability (≤0.1°/h), the accelerometer offers ±10g range with superior stability (≤50μg), and the magnetic sensor features ±8G range with high resolution (3000LSB/G). All three sensing systems are supported by comprehensive signal processing capabilities and operate at up to 1000Hz sampling rate, with the magnetic sensor data available at up to 200Hz. This integration enables high-precision motion and orientation measurement across nine degrees of freedom.

Key Features

  • Measurement range: ±100°/s
  • Exceptional zero bias stability (≤0.1°/h)
  • Superior g-sensitivity (≤0.5°/h/g)
  • Excellent scale factor nonlinearity (≤50ppm)
  • Configurable bandwidth up to 25Hz
  • Measurement range: ±10g
  • Outstanding zero bias stability (≤50μg)
  • Low temperature coefficient (≤0.02mg/°C)
  • Low scale factor nonlinearity (≤300ppm)
  • High bandwidth up to 100Hz
  • Measurement range: ±8G
  • High resolution (3000LSB/G)
  • Superior scale factor nonlinearity (≤0.3%)
  • Update rate up to 200Hz
  • 24-bit resolution for gyro
  • High sampling rate (1000Hz)
  • Precise orthogonality (6°)
  • Fast activation time (≤1s)
  • Wide operating temperature range (-40°C to +85°C)
  • High overload resistance (1000g)

Applications

Complete attitude and heading determinationInertial navigation systemsAdvanced motion tracking and analysisHigh-precision platform stabilizationMulti-sensor fusion applicationsAdvanced robotics controlUnmanned vehicle navigationHigh-end industrial automation

Technical Specifications

Gyroscope Specifications

Measurement Range
±100 °/s
Zero Bias Stability¹
≤0.1 °/h
Zero Bias Temperature Drift²
≤5 °/h
Zero Bias g Sensitivity
≤0.5 °/h/g
Scale Factor Nonlinearity
≤50 ppm
Bandwidth³
25 Hz
Resolution
24 bit

Accelerometer Specifications

Accelerometer Measurement Range
±10 g
Accelerometer Zero Bias Stability¹
≤50 μg
Zero Bias Temperature Coefficient
≤0.02 mg/°C
Scale Factor Nonlinearity
≤300 ppm
Bandwidth³
100 Hz

Magnetic Sensor Specifications

Measurement Range
±8 G
Resolution
3000 LSB/G
Scale Factor Nonlinearity
≤0.3 %

Common Specifications

Orthogonality
6 °
Sampling Rate⁴
1000 Hz
Activation Time
≤1 s
Power Supply Voltage
5~8 V
Current
≤300 mA
Operating Temperature
-40~+85 °C
Resistant To Overload
1000 g

Gyroscope Specifications

Measurement Range
±400 °/s
Zero Bias Stability¹
≤1 °/h
Zero Bias Temperature Drift²
≤5 °/h
Zero Bias g Sensitivity
≤1 °/h/g
Scale Factor Nonlinearity
≤100 ppm
Bandwidth³
200 Hz
Resolution
24 bit

Accelerometer Specifications

Accelerometer Measurement Range
±20 g
Accelerometer Zero Bias Stability¹
≤100 μg
Zero Bias Temperature Coefficient
≤0.02 mg/°C
Scale Factor Nonlinearity
≤300 ppm
Bandwidth³
100 Hz

Gyroscope Specifications

Measurement Range
±500 °/s
Zero Bias Stability¹
≤5 °/h
Zero Bias Temperature Drift²
≤15 °/h
Zero Bias g Sensitivity
≤1 °/h/g
Scale Factor Nonlinearity
≤100 ppm
Bandwidth³
200 Hz
Resolution
24 bit

Accelerometer Specifications

Accelerometer Measurement Range
±50 g
Accelerometer Zero Bias Stability¹
≤200 μg
Zero Bias Temperature Coefficient
≤0.02 mg/°C
Scale Factor Nonlinearity
≤300 ppm
Bandwidth³
100 Hz
  1. [1]Zero bias stability figures use 10 s smoothing; temperature drift figures are 1σ over the full temperature range.
  2. [2]Bandwidth and sampling rate can be customized; magnetic sensor data is available at up to 200 Hz.
  3. [3]Figures shown for the base variant; ±400 °/s and ±500 °/s variants are listed in the full specification tables.

Technical Notes

  1. 10s smoothing
  2. Full temperature
  3. Bandwidth can be customized
  4. Sampling rate can be customized; magnetic sensor data up to 200 Hz

Frequently Asked Questions

What is JDWZZ3430?+

Nine-degree-of-freedom MEMS IMU integrating three-axis gyroscope, accelerometer, and magnetic sensor. Gyroscope zero bias stability down to ≤0.1 °/h, accelerometer ≤50 µg, 24-bit gyro resolution with 1000 Hz sampling; multiple range variants (±100 to ±500 °/s) cover stabilization through high-dynamic navigation.

Which specifications are published for JDWZZ3430?+

Gyroscope Specifications — Measurement Range: ±100 °/s; Gyroscope Specifications — Zero Bias Stability¹: ≤0.1 °/h; Gyroscope Specifications — Zero Bias Temperature Drift²: ≤5 °/h. Measurement conditions: Zero bias stability figures use 10 s smoothing; temperature drift figures are 1σ over the full temperature range. Bandwidth and sampling rate can be customized; magnetic sensor data is available at up to 200 Hz. Figures shown for the base variant; ±400 °/s and ±500 °/s variants are listed in the full specification tables. See the technical specifications for the complete parameter list.
