50–56 V Thermal Battery Series

Thermal Battery · CDR56FLX

50 V platform thermal battery series with capacities from 450 As to 18,000 As, pulse currents up to 120 A, and activation in under 0.8 s. Compact 36–50 mm diameters, 0.2–0.9 kg across variants.

Request a quote View specifications
50–56 V Thermal Battery Series
CDR56FLXProduct reference

Confirm configuration, interfaces and documentation with your inquiry.

The CDR50FLX series represents our 50V platform thermal batteries, offering capacities from 450As to 1100As. These compact units feature fast activation times under 0.8s and provide reliable power output with pulse current capabilities up to 40A. Ideal for applications requiring moderate power delivery and quick response times.

Key Features

  • 50V nominal voltage platform
  • Compact size with diameter range 36-50mm
  • Ultra-fast activation time less than 0.8s
  • Capacity options from 450As to 3200As
  • Pulse current capabilities up to 70A
  • Lightweight design from 0.2kg to 0.9kg

Applications

Portable military equipmentSmall-scale guided weaponsEmergency power systemsTactical communication devicesMobile defense platforms

Technical Specifications

Basic Parameters

CDR50FLX01
0.200 kg Φ36×90 mm
CDR50FLX02
0.263 kg Φ40×75 mm
CDR50FLX03
0.900 kg Φ45×180 mm
CDR50FLX04
0.390 kg Φ50×78 mm

Electrical Parameters

CDR50FLX01
50 V 450 As
CDR50FLX02
50 V 480 As
CDR50FLX03
50 V 3200 As
CDR50FLX04
50 V 1100 As

Performance Parameters

CDR50FLX01
<0.8 s 25 A
CDR50FLX02
<0.8 s 30 A
CDR50FLX03
<0.8 s 70 A
CDR50FLX04
<0.8 s 40 A

Basic Parameters

CDR54FLX01
1.900 kg Φ78×160 mm

Electrical Parameters

CDR54FLX01
54 V 6750 As

Performance Parameters

CDR54FLX01
<1.0 s 120 A

Basic Parameters

CDR55FLX01
0.520 kg Φ50×90 mm

Electrical Parameters

CDR55FLX01
55 V 1200 As

Performance Parameters

CDR55FLX01
<0.8 s 40 A

Basic Parameters

CDR56FLX01
1.580 kg Φ67×170 mm
CDR56FLX02
4.300 kg Φ96×227 mm

Electrical Parameters

CDR56FLX01
56 V 5600 As
CDR56FLX02
56 V 18000 As

Performance Parameters

CDR56FLX01
<2.0 s 60 A
CDR56FLX02
<2.0 s 100 A
  1. [1]Each row of the specification tables corresponds to one variant in the series; figures differ by variant — confirm the exact variant at inquiry.

Technical Notes

  1. Operating temperature range: -40°C to +70°C
  2. Pulse current capability refers to the maximum current amplitude the battery can withstand
  3. Working current profiles are optimized for specific application scenarios.

Frequently Asked Questions

What is CDR56FLX?+

50 V platform thermal battery series with capacities from 450 As to 18,000 As, pulse currents up to 120 A, and activation in under 0.8 s. Compact 36–50 mm diameters, 0.2–0.9 kg across variants.

Which specifications are published for CDR56FLX?+

Basic Parameters — CDR50FLX01: 0.200 kg Φ36×90 mm; Basic Parameters — CDR50FLX02: 0.263 kg Φ40×75 mm; Basic Parameters — CDR50FLX03: 0.900 kg Φ45×180 mm. Measurement conditions: Each row of the specification tables corresponds to one variant in the series; figures differ by variant — confirm the exact variant at inquiry. See the technical specifications for the complete parameter list.
