High-Voltage Thermal Battery Series (100–150 V)

Thermal Battery · CDR157FLX

High-voltage thermal battery series on 100 V and 150 V platforms, with capacities from 880 As to 40,000 As, power output up to 4,400 W, pulse current up to 300 A, and operating durations up to 900 s. Fast activation for high-energy applications.

Request a quote View specifications
High-Voltage Thermal Battery Series (100–150 V)
CDR157FLXProduct reference

Confirm configuration, interfaces and documentation with your inquiry.

The CDR100FLX series delivers exceptional performance with a voltage range of 82V-115V and power output up to 4400W. Featuring capacities from 880As to 40000As and pulse currents up to 300A, these batteries are engineered for demanding high-power applications.

Key Features

  • 100V nominal voltage platform
  • Wide voltage range 82V-115V
  • High pulse current up to 300A
  • Extended operation up to 900s
  • Power output up to 4400W
  • Multiple capacity options

Applications

High-energy weapon systemsAdvanced missile guidanceCritical defense infrastructureLong-duration military operationsStrategic defense platforms

Technical Specifications

Basic Parameters

CDR100FLX01
0.650 kg Φ50×135 mm
CDR100FLX02
1.650 kg Φ67×185 mm
CDR100FLX03
8.400 kg Φ110×370 mm

Electrical Parameters

CDR100FLX01
100 V 880 As
CDR100FLX02
100 V 5100 As
CDR100FLX03
100 V 40000 As

Performance Parameters

CDR100FLX01
<0.8 s 30 A
CDR100FLX02
<1.0 s 100 A
CDR100FLX03
<2.0 s 300 A

Basic Parameters

CDR135FLX01
1.150 kg Φ57×170 mm
CDR135FLX02
2.750 kg Φ78×215 mm

Electrical Parameters

CDR135FLX01
135 V 1100 As
CDR135FLX02
135 V 4200 As

Performance Parameters

CDR135FLX01
<0.5 s 50 A
CDR135FLX02
<1.0 s 40 A

Basic Parameters

CDR157FLX01
8.300 kg Φ107×360 mm

Electrical Parameters

CDR157FLX01
157.5 V 20000 As

Performance Parameters

CDR157FLX01
<1.5 s 300 A
  1. [1]Each row of the specification tables corresponds to one variant in the series; figures differ by variant — confirm the exact variant at inquiry.

Technical Notes

  1. Operating temperature range: -40°C to +70°C
  2. Pulse current capability refers to the maximum current amplitude the battery can withstand
  3. Working current profiles are optimized for specific application scenarios.

Frequently Asked Questions

What is CDR157FLX?+

High-voltage thermal battery series on 100 V and 150 V platforms, with capacities from 880 As to 40,000 As, power output up to 4,400 W, pulse current up to 300 A, and operating durations up to 900 s. Fast activation for high-energy applications.

Which specifications are published for CDR157FLX?+

Basic Parameters — CDR100FLX01: 0.650 kg Φ50×135 mm; Basic Parameters — CDR100FLX02: 1.650 kg Φ67×185 mm; Basic Parameters — CDR100FLX03: 8.400 kg Φ110×370 mm. Measurement conditions: Each row of the specification tables corresponds to one variant in the series; figures differ by variant — confirm the exact variant at inquiry. See the technical specifications for the complete parameter list.
