K-CDR-90FLX
CDR090FLX
90V thermal battery series with voltage range 71.6V-100V, featuring capacities from 400As to 24000As and pulse currents up to 180A
Customizable Parameters
Specifications shown are reference configurations. Most parameters can be adjusted to meet your application requirements.
The CDR090FLX series represents our 90V platform thermal batteries, offering a wide voltage range of 71.6V-100V. With capacities from 400As to 24000As and pulse currents up to 180A, this series provides robust power solutions for high-voltage applications requiring substantial power delivery.
Key Features
- 90V nominal voltage platform
- Wide voltage range 71.6V-100V
- Ultra-fast activation time ≤1.0s
- Capacity range 400-24000As
- High pulse current up to 180A
- Power output up to 5373W
Applications
High-voltage weapon systemsAdvanced missile platformsHeavy-duty military equipmentLong-range defense systemsHigh-power tactical applications
Specifications
Basic Parameters
| CDR090FLX01 | 0.450 kgΦ45×110 mm |
| CDR090FLX02 | 2.800 kgΦ85×180 mm |
| CDR090FLX03 | 5.250 kgΦ95×290 mm |
Electrical Parameters
| CDR090FLX01 | 90 V400 As |
| CDR090FLX02 | 90 V5300 As |
| CDR090FLX03 | 90 V24000 As |
Performance Parameters
| CDR090FLX01 | <0.8 s20 A |
| CDR090FLX02 | <1.0 s180 A |
| CDR090FLX03 | <1.0 s120 A |
Technical Notes
- Operating temperature range: -40°C to +70°C
- Pulse current capability refers to the maximum current amplitude the battery can withstand
- Working current profiles are optimized for specific application scenarios.
Request a Quote
All specifications can be customized. Tell us your requirements for a tailored solution.
